Swivelpole™ S2 M1 HVPT
2.4 - 3.0m
High vibration
Stanchion mounted
Stanchion mounted
Quick links
Details
- Designed for installation in accordance with IEC standards.
- With High Vibration Pole Top
- Ideal for lighting on walkways, platforms, stairways, and conveyors.
Standard pole top/base finish options
- Hot-dip galvanised (HG)
Standard Maxis™ joint finishes
- Hot-dip galvanised (HG)
Support material
User guides
Technical
Where to buy?
Ordering information
| Installed height | Pole top | Pole top length | Pole base | Pole base length | Pole weight | Max equipment weight* | Maxis™ joint finish | Pole finish | Product code |
|---|---|---|---|---|---|---|---|---|---|
| 2.4m | DN 40 | 1250mm | DN 50 | 1250mm | 17.6kg | 20kg | HG | HG | S2-M1-HVPT-2400-P-001-HG |
| 3.0m | DN 40 | 1750mm | DN 50 | 1250mm | 19.4kg | 20kg | HG | HG | S2-M1-HVPT-3000-P-001-HG |
- HG: Hot-dip galvanised · All dimensions are nominal, in metric sizes.
- *Maximum equipment weight refers to operational limits, not its structural capacity and includes the total of any equipment and its mounting bracket.
Related products
Mounting brackets
MBK2-2-50
Stanchion
MBK6-6-50
Stanchion
Junction box plates
JBPK1208-50
Single offset
JBPK1201-50
Double centred
